Accurate regulation of an optimal
airflow rate for precise motion control.
The
compact design provides the comparable range of
speed as the larger ones do.
Control-out and
control-in types are available for all
models.
All R and NPT threads are pre-coated
sealant. |
| |
|
 |
|
|
 |
|
|
|
|
| Fluid Type |
Air (No other type of gas or
liquid) |
| Working Pressure Range |
0~150PSI |
0~9.9KgF/cm2(0~990KPa) |
| Negative
Pressure |
-29.5 in Hg |
-750mm Hg(10
Torr) |
| Working
Temperature |
32~140°F |
0-60℃ |
|
| |
| JSC |
MODEL(φD-T) |
| Tube(Metric)-Thread(R) |
Tube(Inch)-Thread(R) |
Tube(Inch)-Thread(NPT) |
| JSC
04-M5 |
JSC
08-02 |
JSC
12-04 |
JSC
1/4-M5 |
JSC
5/32-U |
JSC
1/4-N3 |
JSC
1/2-N4 |
| JSC
04-01 |
JSC
08-03 |
|
JSC
1/4-01 |
JSC
5/32-N1 |
JSC
5/16-N1 |
|
| JSC
04-02 |
JSC
08-04 |
|
JSC
1/4-02 |
JSC
3/16-U |
JSC
5/16-N2 |
|
| JSC
06-M5 |
JSC
10-01 |
|
JSC
5/16-01 |
JSC
3/16-N1 |
JSC
5/16-N3 |
|
| JSC
06-01 |
JSC
10-02 |
|
JSC
5/16-02 |
JSC
3/16-N2 |
JSC
5/16-N4 |
|
| JSC
06-02 |
JSC
10-03 |
|
JSC
5/16-03 |
JSC
3/16-N3 |
JSC
3/8-N2 |
|
| JSC
06-03 |
JSC
10-04 |
|
JSC
3/8-02 |
JSC
1/4-U |
JSC
3/8-N3 |
|
| JSC
06-04 |
JSC
12-02 |
|
JSC
3/8-03 |
JSC
1/4-N1 |
JSC
3/8-N4 |
|
| JSC
08-01 |
JSC
12-03
|
|
|
JSC
1/4-N2 |
JSC
1/2-N3 |
|
|
|
| |
|
|
|
|
| JSU |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| JSU
04 |
JSU
5/32 |
| JSU
06 |
JSU
3/16 |
| JSU
08 |
JSU
1/ 4 |
| JSU
10 |
JSU
5/16 |
| JSU
12 |
JSU
3/ 8 |
|
JSU
1/ 2 |
| |
|
| |
|
| |
|
|
|
| |
|
|
| JSC-G |
MODEL(φD-T) |
| Tube(Metric)-Thread(G) |
| JSC
04-G01 |
JSC
08-G04 |
| JSC
04-G02 |
JSC
10-G01 |
| JSC
06-G01 |
JSC
10-G02 |
| JSC
06-G02 |
JSC
10-G03 |
| JSC
06-G03 |
JSC
10-G04 |
| JSC
06-G04 |
JSC
12-G02 |
| JSC
08-G01 |
JSC
12-G03 |
| JSC
08-G02 |
JSC
12-G04 |
| JSC
08-G03 |
|
|
|
